TABLE 13: Electrical Data - (For Multi-Source Power Supply) - Copper Wire 1 Ø - 208/230-1-60
Models
MV
Heater
Models
Min. Circuit Ampacity Max. O.C.P. Amps/Type 1 75°C Wire Size - AWG
Circuit Circuit Circuit
1st 2nd 3rd 1st 2nd 3rd 1st 2nd 3rd
208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230
12B
4HK16501306 41.7/47.9 22.4/25.0 – 50/50 30/30 – 6/6 12/10 –
4HK165N1506 49.2/55.4 21.7 / 25.0 – 50/60 25/25 – 8 / 6 10/10 –
12D
4HK16501306 41.7/47.9 22.4/25.0 – 50/50 30/30 – 6/6 12/10 –
4HK16501506 49.2/55.4 21.7/25.0 – 50/60 25/25 – 8 / 6 10/10 –
4HK16501806 45.6/51.2 39.7/45.8 – 50/60 40/50 – 8 / 6 8/8 –
4HK16502006 49.2/55.4 43.3/50.0 – 50/60 45/50 – 8 / 6 8/8 –
16C
4HK16501306 42.9/49.1 23.6/26.2 – 50/50 30/30 – 6/6 12/10 –
4HK16501506 51.0/56.9 21.7/25.0 – 50/60 25/25 – 8 / 6 10/10 –
4HK16501806 17.3/52.7 39.7/45.8 – 50/60 40/50 – 8 / 6 8/8 –
4HK16502006 51.0/56.9 43.3/50.0 – 50/60 45/50 – 8 / 6 8/8 –
20D
4HK16501306 43.9/50.1 24.6/27.2 – 50/60 30/30 – 6/6 10/10 –
4HK16501506 53.1/58.8 21.7/25.0 – 60/60 25/25 – 6 / 6 10/10 –
4HK16501806 49.5/54.6 39.7/45.8 – 50/60 40/50 – 8 / 6 8/8 –
4HK16502006 53.1/58.8 43.3/50.0 – 60/60 45/50 – 6 / 6 8/8 –
4HK16502506 49.3/56.5 43.3/50.0 21.7/25.0 50/60 45/50 25/25 8 / 6 8/8 10/10
1. O.C.P. = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
TABLE 14: Electrical Data - (For Multi-Source Power Supply) - Copper Wire - 208/230-3-60
Models
Heater
Model
Minimum Circuit Ampacity Max. O.C.P. 1 Amps/Type 75°C Wire Size - AWG
Circuit
1st 2nd 3rd 1st 2nd 3rd 1st 2nd 3rd
208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230
20D 4HK16502525 41.0/44.9 31.3/36.1 – 45/45 35/40 – 8/8 8/8 –
1. O.C.P. = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
