11
Dry
The dry setting is best suited to parts of the country where excessive
humidity is not generally a problem, where the summer months are usu-
ally dry. On a call for cooling the motor will ramp up to full capacity and
will stay there until the thermostat is satisfied. At the end of the cooling
cycle, the blower will ramp down to 50% of full capacity where it will stay
for 60 seconds. Then it will ramp down to zero.
Temperate
The temperate setting is best suited for most of the country, where nei-
ther excessive humidity nor extremely dry conditions are the norm. On
a call for cooling, the motor will ramp up to 63% of full capacity and will
stay there for 90 seconds, then will ramp up to full capacity. At the end
of the cooling cycle, the motor will ramp down to 63% of full capacity
and will stay there for 30 seconds, then will ramp down to zero.
SECTION IX: UNIT DATA
TABLE 6: Physical and Electrical Data - Cooling Only (60 Hz)
Models MV12B MV12D MV16C MV20D
Blower - Diameter x Width 10 x 7 10 x 10 10 x 10 10 x 10
Motor
HP 1/2 1/2 3/4 1
Nominal RPM 1200 1200 1200 1200
Voltage 230
Amps Full Load (230) 4.3 4.3 5.0 7.0
Permanent Filter 1
Type DISPOSABLE OR PERMANENT
Size 16 x 20 x1 24 x 20 x 1 20 x 20 x 1 24 x 20 x1
Filter Bulk Pack 1PF0601BK 1PF0604BK 1PF0602BK 1PF0604BK
Shipping / Operating Weight (lbs.) 75/71 88/82 88/82 94/88
1. Field Supplied.
TABLE 7: Electrical Data - Cooling Only (60 Hz)
Models
Total Motor Amps Minimum Circuit Ampacity
Max. O.C.P.
Amps/Type 1
Minimum Wire
Size A.W.G.
60 Hertz 60 Hertz
208V 230V 208V 230V
12B 4.7 4.3 5.9 5.4 15 14
12D 4.7 4.3 5.9 5.4 15 14
16C 6.1 5.0 7.6 6.9 15 14
20D 7.8 7.0 9.7 8.8 15 14
1. OCP = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
TABLE 8: Conversion Table
kW & MBH Conversions - for Total Power Input Requirement
FOR
208V
OPERATION MULTIPLY
240V
TABULATED kW & MBH BY
.751
230V 240V .918
220V 240V .840
