Chapter 2 : Installation and Setup
10 - Elo Entuitive Touchmonitor CRT Rear Mount User Guide
4. The OSD controls and the Soft Power switch are located on a
panel inside the bottom of your monitor. Power on your monitor
using the Soft power switch and check that the power LED is on,
then power on your PC. If the LED is not on, repeat steps 2, 3,
and 4, or refer to Chapter 4, Troubleshooting.
5. After a brief pause the picture should appear. If necessary, adjust
the OSD controls according to your personal preference (see
Chapter 3).
6. Insert the Elo TouchTools CD-ROM in your computer’s CD-
ROM drive to install the appropriate touchscreen driver soft-
ware. Follow the directions starting on the next page to install
the driver software.
Menu
Select
Brightness
Contrast
Power LED
Soft Power Switch
Underside view of the touchmonitor
