6
Present the Proximity Tag as shown below Present the Proximity Tag as shown below Present the Proximity Tag as shown below Present the Proximity Tag as shown below::::
Technical Specifications Technical Specifications Technical Specifications Technical Specifications
Current Consumption
ProSYS KP
ProSYS KPP
13.8V +/-10%, 30 mA typical/180 mA max.
13.8V +/-10%, 30 mA typical/280 mA max.
Main Panel Connection 4-wire BUS, up to 300 m (1000 ft) from Main
Panel
Dimensions 210 mm x 152 mm x 20 mm (8.2" x 5.9" x 0.7")
Operating temperature 0°C to 49°C (32°F to 120°F)
Storage temperature -20°C to 60°C (-4°F to 140°F)
Prox. RF Frequency 13.56MHz
Maintenance Maintenance Maintenance Maintenance
•
To clean the LCD Screen: To clean the LCD Screen: To clean the LCD Screen: To clean the LCD Screen: Lock the keypad (see page 5). Use a non-abrasive
damp cloth. Do not expose the screen directly to liquid.
• Change the user codes regularly.
Ordering Information Ordering Information Ordering Information Ordering Information
Model Description
ProSYS KP Touchscreen Keypad
ProSYS KPP Touchscreen Keypad with Proximity 13.56MHz
RP200KT 10 prox keytags for Touchscreen & Agility (13.56MHz)
