PC/104-Plus – COM-1460 Module
A.2 Mechanical
Dimensions
Module Dimensions
The COM-1460 module’s mechanical dimensions are shown in the following picture:
Dimensions: 90 X 96 mm (3.6”X3.8”), height 15 mm (0.6”)
96.0
90
.2
5.1
5.
1
4.
6
5.1
18.5
8.0
10
.2
6.1
2.54
8.
9
9.0
7.6
Ø 6.4 PAD
Ø 3.2 HOLE
73
.7
5.1
12.1
12.1
12.1
Dimensions are in millimeters
Figure 9.
COM-1460 Board dimensions
Note: For further information about the mechanical dimensions of ISA and PCI buses please
refer to the PC/104 consortium site (
