Video Wall Projection
Master
Set Inputs
ON
ON
OFF
OFF
ON
OFF
ON
OFF
OFF
OFF
ON
OFF
Slave
Set Inputs
COMPUTER1
COMPUTER2
DVI
HDMI
VIDEO
S-VIDEO
COMPUTER1
COMPUTER2
DVI
HDMI
VIDEO
S-VIDEO
Projector 1 Projector 2-4
13
Repeat the same procedure from
the step 10 to 12 for the projector 3
and 4.
14
Select inputs as specified in the
table on the right.
(See page 63 on the owner’s manual of the
projector.)
Note
• Set input terminals you will use to “ON”.
Set input terminals you will not use to
“OFF”.
15
Turn off all of the projectors.
16
Make connections following the
diagram shown on page
49 .
17
Turn on the projectors first, then
turn on the computers and the
video equipment.
Note
• Image quality may deteriorate when picture sig-
nals are input through multiple projectors with
an RGB cable in a daisy chain connection.
