Assembly
Mixing bowl with kneading knife, cutting knife or
emulsifying disc
NOTE
► Use the diagrams on the fold-out page for assembly assistance!
1) Attach the drive shaft i to the shaft holder.
2) Place the mixing bowl u onto the motor block o in such a way that the ar-
row is pointing at the symbol and rotate the mixing bowl u until the
arrow is pointing at the symbol . The mixing bowl u is now fi xed.
3) Put the drive shaft adapter z onto the drive shaft i.
4) Now choose your insert:
–
the kneading knife r for stirring cake dough,
–
The cutting knife t for chopping onions, Parmesan cheese and the
like, or
–
the emulsifying disc 4 for whipping cream, beating egg white or
making light desserts.
■ Kneading r or cutting knife t: Slide the kneading knife r or the cutting
knife t onto the drive shaft adapter z so that the locking mechanisms
engage.
■ Emulsifying disc 4: F it the emulsifying disc 4 to the drive shaft adapter z
in such a way that the locking mechanisms engage.
5) Put the lid 3 onto the mixing bowl u so that the arrow on the lid 3 points to
the symbol (white square) on the mixing bowl u. Then rotate it until an au-
dible “click” is heard and the arrow is pointing to the symbol (white arrow).
6) Slide the pusher 1 into the fi lling shaft 2.
7) Insert the plug into the mains power socket.
