9. Lift the cover from the engine and lay to the front of the trimmer.
NOTE
The throttle linkage remains assembled to the cover.
10. Reinstall spark plug to prevent dirt and debris from entering engine.
11. Use a brush to remove dirt from the cylinder fins.
IMPORTANT
DO NOT use a metal scraper to remove dirt from the cylinder fins.
12. Remove grass and leaves from the grid between the starter and fuel
tank.
13. Reassemble parts in reverse order of removal. When installing the
cover, be certain:
• the tabs of the deflector shield (A) are in the slots of the cover
• the fuel check valve (B) is positioned in the cover
• the spark plug (C) is tightened securely
• the ignition wire (D) is not pinched
14. When installing EZR starter housing to EZR mounting body, be sure
that EZR drive starter cam engages the starter pawl correctly.
