Kit Contents
2-2 Installation and Connection
Kit Contents
The 20-port Mid-Span Power Hub may be placed on a shelf or mounted in a standard 19-inch
rack.
The 10-port Mid-Span Power Hub may be placed on a shelf or mounted in a standard 19-inch
rack using the BL-89210-RMENT rack mount kit (optional).
Figure 2-1 BL-89420ENT, BL-89520ENT, BL-89620ENT, or BL-89720ENT
20-Port Mid-Span Power Hub
Figure 2-2 BL-89710ENT 10-Port Mid-Span Power Hub
Power Cord
User’
s
Guide
Power Cord
User’
s
Guide
