INSTALLATION DIAGRAM
SCHEMA DI INSTALLAZIONE
I = electrical connection
K = position of cables for fixing the appliance
I = connessione elettrica
K = posizione cordini per fissaggio apparecchiatura
I = branchement électrique
K = position des câbles de fixation de l'appareil
I = conexión eléctrica
K = posición de los cables para inmovilizar el aparato
105.66 Gallons / 400 Liters
105,66 Galloni / 400 litri
SCHÉMA D'INSTALLATION
DIAGRAMA DE INSTALACIÓN
105,66 gallons / 400 litres
105,66 galones / 400 litros
