2 dsa250i, Right side, Bottom – EAW DSA250i User Manual
Page 49: Front dsa250i, Back
9.2
DSA250i
45
50.80
26.00
50.80
DESCRIPTION
CABINET/FINISHED/WHITE/DSA250i/230 V
CABINET/FINISHED/WHITE/DSA250i/115 V
PRODUCTION
RIGHT SIDE
DIMENSIONS APPLY
TO BOTH SIDES
9.34
9.32
INPUT PANEL
POWER END
BOTTOM
GRILLE PARTIALLY SHOWN
GRILLE PARTIALLY SHOWN
0015158-00
DRAWING NO.
0015158-01
FRONT
DSA250i
EASTERN ACOUSTIC WORKS
BACK
115 V
VOLTAGE
230 V
2X 14°
NOTES:
1. SYMBOL
INDICATES CENTER OF BALANCE.
2. WEIGHT APPROX. 84 LB.
3. SHIPPING WEIGHT APPROX. 100 LB.
INPUT PANEL
2X 20°
SIGNAL END
L
C
TOP
LED
5.88
