EAW UB52 User Manual
Back, Bottom, Ub52
9.88
PRODUCTION
3.40
7.00
BACK
DIMENSIONS APPLY TO
TOP AND BOTTOM
2.12
INPUT
BOTTOM
EASTERN ACOUSTIC WORKS
UB52
6.28
GRILLE PARTIALLY
SHOWN
FRONT
19.75
NOTES:
1. SYMBOL
INDICATES MOUNTING
POINT,1/4-20 THREADED HOLE.
2. SYMBOL
INDICATES CENTER OF
BALANCE.
3. WEIGHT APPROX. 19 LBS.
4. SHIPPING WEIGHT APPROX. 21 LBS.
8.13
SIDES
DIMENSIONS APPLY
TO BOTH SIDES
4.63
2.88
L
C
