EAW VR51 - Manual

Part No. SW0506 Rev. A 04/07
30.00 in/
762.0 mm
19.40 in/
492.7 mm
18.97 in/
481.9 mm
19.40 in/
492.7 mm
0.65 in/
16.4 mm
8.93 in/
226.7 mm
FRONT SIDES BACK TOP & BOTTOM
30.00 in/
762.0 mm
19.40 in/
492.7 mm
18.97 in/
481.9 mm
19.40 in/
492.7 mm
0.65 in/
16.4 mm
8.93 in/
226.7 mm
FRONT SIDES BACK TOP & BOTTOM
DESCRIPTION
The VR51 has been engineered as a high output full range
solution for a wide range of applications, from music and speech
reinforcement to delay or fill coverage. Two horns are included with
each VR51: the factory-installed low Q horn can easily be rotated or
replaced with a high-Q horn as needs dictate. The ability to select
among four coverage patterns with either vertical or horizontal
mounting makes the VR51 a uniquely versatile solution. High
acoustic output capabilities enable the VR51 to deliver clear speech
and clean music to large audience areas.
The cross-ply laminated birch enclosure includes several threaded
mounting points, suitable for use with either forged shoulder
eyebolts or a user-supplied OmniMount 120.0 Series wall mount
bracket. The VR51 is available in either black or white finishes. A
foam-backed powder-coated steel grill protects the drivers. The
entire loudspeaker is fully tested at the time of manufacture and is
warranted to be free from defects in materials and workmanship for
a period of five years from the date of purchase.
VR 51
TWO-WAY LOUDSPEAKER
• Both low-Q and high-Q horns included
• Rotatable horns and multiple threaded inserts allow
vertical or horizontal mounting
• High SPL full range output with 15 inch LF & 1.4 inch
HF drivers
• Integral passive crossover network allows economical
single-amplifier powering
• Optional 70 V / 100 V multi-tap transformer (AC-TX 128)
• 3/8”-16 mounting points
Features
• Houses of Worship • Distributed Systems
• Night Clubs • Theaters
• Audiovisual Presentation • Theme Parks
• Retail Environments
Applications
Eastern Acoustic Works | One Main Street | Whitinsville, MA 01588 USA | TEL toll free within US/Canada 888.337.7404
TEL outside US 425.892.6503 | FAX 425.485.1152 | Page 1 of 4
VR51 DIMENSIONS
