REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

HANDLE - FRONT

1

C400000000

1

GRIP, HANDLE

1

35131102330

2

INCLUDES ITEMS 4-8

HANDLE BRACKET KIT

1

P021015820

3

BOLT

1

35142152130

4

WASHER

1

60501454230

5

NUT

1

90056550008

6

SCREW - 5X20

2

V805000160

7

SCREW - 5X25

3

V805000170

8

INCLUDES ITEMS 10-12

THROTTLE CONTROL ASY

1

35110247530

9

SCREW - 3X25

4

90024603025

10

SCREW - 5X30

1

90022005030

11

NUT - 5

1

90050000005

12

TRIGGER, THROTTLE

1

17801005960

13

CLIP

1

15911209961

14

TUBE, PROTECTIVE - CORRUGATED

1

V475000000

15

CABLE, THROTTLE

1

V430002280

16

NUT - 6 -- FLANGE

1

90051800006

17

NUT - 6

1

90050200006

18

SPRING, THROTTLE LOCK

1

17801335631

19

LOCKOUT, TRIGGER

1

17801205960

20

SWITCH, IGNITION

1

A440001250

21

SCREW - 3X10

1

9154503010

22

KNOB

1

A444000020

23

CLIP

2

22492452130

24

99922200785

- 39 -

REVISED 05/08/12
