Echo SRM-225U User Manual
Page 13

REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
CARBURETOR -- RB-K93
1
A021001690
SCREW
3
12534413931
1
SCREW
1
12534452130
2
SWIVEL
1
P005001240
3
RING, RETAINING
1
P005000190
4
SCREW, IDLE ADJUST
1
P005000100
5
ROTOR COVER ASY
1
P005002050
6
O-RING
1
P005000280
7
SCREW, PURGE BULB RETAINER
4
P005001900
8
RETAINER, PURGE BULB
1
P005000250
9
BULB, PURGE
1
12538108660
10
SCREW, PURGE BASE
1
P005000270
11
BASE, PURGE
1
P005001890
12
CAP, LIMITER
1
P005001270
13
NEEDLE - HIGH SPEED
1
P005001260
14
SCREW
2
12534452130
15
COVER, METERING
1
12534252130
16
SCREW, METERING LEVER PIN
1
12533942030
17
Includes ITEMS 19-28
REPAIR KIT
1
P005001670
18
GUIDE, ROLLER
1
P005001000
19
GASKET, PUMP
1
------------------
20
DIAPHRAGM, PUMP
1
------------------
21
STRAINER
1
------------------
22
SPRING, METERING LEVER
1
------------------
23
VALVE, INLET NEEDLE
1
------------------
24
PIN, METERING LEVER
1
------------------
25
LEVER, METERING
1
------------------
26
DIAPHRAGM, METERING
1
------------------
27
GASKET, DIAPHRAGM
1
------------------
28
Includes ITEMS 30-33
DIAPHRAGM/GASKET KIT
1
P005001660
29
GASKET, PUMP
1
------------------
30
DIAPHRAGM, PUMP
1
------------------
31
DIAPHRAGM, METERING
1
------------------
32
GASKET, DIAPHRAGM
1
------------------
33
NOT AVAILABLE SEPARATELY
BODY, CARBURETOR
1
1
------------------
34
Included In Kit
RePower FUEL SYSTEM KIT
2
90127
FS
Footnotes
1: NOT AVAILABLE SEPARATELY
2: Included In Kit
99922200785
- 13 -
REVISED 05/08/12
SRM-225U Brushcutter
Carburetor -- RB-K93
