REMARKS DESCRIPTION QTY PART NUMBER ITEM
THUMBSCREW 1 V299000250 1
COVER, AIR CLEANER 1 A232000480 2
FILTER, AIR - DOUBLE LAYER 1 A226001410 3
OPTIONAL FILTER, AIR - SINGLE LAYER 1 1 13031054130 4
SCREW - 5X65 -- TORX 2 V805000100 5
NUT - 5 2 90050000005 6
PLATE, PREVENT 1 12901152730 7
CASE, AIR CLEANER 1 P021012870 8
See Carburetor Diagram For Details CARBURETOR 2 1 ------------------ 9
Included In GASKET KIT GASKET, INTAKE 3 1 V103001500 10
SCREW - 5X20 2 V805000160 11
INSULATOR, INTAKE 1 13001744331 12
Included In GASKET KIT SHIELD, INTAKE 3 1 V103001360 13
Included In Kit RePower TUNE-UP KIT 4 90074 TU
Included In Kit RePower FILTER KIT 4 90008 FF
Footnotes
1: OPTIONAL
2: See Carburetor Diagram For Details
3: Included In GASKET KIT
4: Included In Kit
99922200785 - 11 - REVISED 05/08/12
Table of Contents Part Number Index
SRM-225U Brushcutter Intake
