REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

USE .095" DIAMETER TRIMMER LINE

U-TURN HEAD

1

X047000410

BOLT, SHAFT

1

215601

1

Includes ITEM 3

HOUSING

1

X470000160

2

INCLUDES 2 PER PACKAGE

EYELET

2

2

X475000040

3

SPRING

1

V450000660

4

DRIVE, OUTER

1

X471000040

5

CAM, INNER

1

X471000050

6

NUT

1

V265000100

7

SPOOL

1

X473000000

8

Footnotes

1: USE .095" DIAMETER TRIMMER LINE
2: INCLUDES 2 PER PACKAGE

99922200785

- 27 -

REVISED 05/08/12

Table of Contents

Part Number Index

SRM-225U Brushcutter

U-Turn Head
