Introduction
|
19
Control Panel
LCD Screen
LCD
screen
Power
light and
button
Pause/reset
light and button
Ink
light
Left arrow or paper
source button
Paper
light
Menu button
Paper feed up button
Paper feed down button
OK button
Paper cut
button
Ink open button
Black ink change button
Paper release (ePlaten
™
)
light and button
Platen
gap
Paper
source
Roll paper
margin
Paper
number
Ink cartridge
status
Roll paper
counter
Maintenance
tank status
Black ink
indicator
Auto Take-Up Reel
Spectro
Proofer
