Introduction
Printer Parts
These illustrations show the Epson Stylus Pro 9890, but the parts are the
same for the Pro 7890 unless otherwise noted.
Front
Back
Roll paper cover
Control
panel
Ink bay
Ink bay
Front
cover
Paper basket
Casters
Roll paper
holder
Network interface
USB interface
for computer
AC inlet
Maintenance tank
(Pro 9890 includes
two tanks, one on
each side of printer)
Interface
connector
for optional
equipment
