ActionPrinter 3250
Environmental
Temperature Operation: 5 to 35°C (41 to 95°F)
Storage: -20 to 55°C (4 to 131°F)
Humidity (without condensation):
Operation: 30 to 80% RH
storage: 5 to 85% RH
Safety approvals
Safety Standards:
US
model: UL1950 with D3, CSA22.2 #220
European model: EN 60950 (TUV), IEC 950 (SEMKO, DEMKO,
NEMKO, SETI)
RFI: US model: FCC class B
European model: VDE0871, CISPR PUB.22
Interface specifications
Your printer is equipped with an 8-bit parallel interface with
the following characteristics:
Data format: 8-bit parallel
Synchronization:
Handshake timing:
Signal level:
Connector:
STROBE pulse
BUSY and ACKNLG signals
TTL compatible
36-pin 57-30360 Amphenol connector or
equivalent
Default settings
Item
Top of farm position
Page length
Left and right margins
Line spacing
Character size
Horizontal tab positions
Font selection
Special printing effects
Download character set
Default setting
Current paper position or setting in the default
setting mode.
Single sheets: 65 lines for A4-size paper,
61 lines for letter-size paper, 22 inches for
manual insertion
Continuous paper: Subject to control panel
setting in the default-setting mode
Canceled
1/6-inch tine spacing
10.5 point
Every eight characters
Last font selected on control panel
Canceled (except condensed printing)
Hardware initialization: cleared
Software initialization: deselected only
In addition, hardware initialization clears the data buffer.
Character Tables
These character tables are selected with the default-setting mode or by wing a
software command. AU the tables are the same for hex codes 00 through 7F.
Therefore, only first table is shown completely. The rest of the tables show only the
characters for hex codes 80 through FF.
For all character tables except the italic character table, the ESC 6 and ESC 7
software commands let you select whether hex codes 80 to 9F are characters (EX 6)
or control codes (ESC 7).
PC 437 (USA, standard Europe)
Character available with ESC (^
To print the characters in the table below, you must first send the ESC (^ command.
24-Pin Printers 3/17/92 AP-3250-3
