C H A P T E R 3 O S D M E N U A N D C O N F I G U R A T I O N
40
z Please turn mini-joystick UP (c) or DOWN (d) to move between TOP, DOWN, LEFT and
RIGHT for adjusting the size of the area.
z Please turn mini-joystick LEFT (e) or RIGHT (f) to adjust the value for size of the area.
z Additionally, it is possible to change the position of the area. Please refer to the following
example for detailed steps on moving AREA1 to center.
1. The original position of AREA1 was TOP: 10, DOWN: 25, LEFT: 20 and RIGHT: 40.
2. Increase DOWN scale value by 20. AREA1 position after change is: TOP: 10, DOWN: 45, LEFT:
20 and RIGHT: 40.
AREA1 AREA2
AREA3 AREA4
AREA1
AREA1
