C H A P T E R 3 O S D M E N U A N D C O N F I G U R A T I O N
38
3.1.8.2 COLOR ADJ
Adjust the Color Gain from 0 ~ 15
3.1.8.3 SYNC
There are two SYNCHRONIZATION modes: INTERNAL and EXTERNAL LINE-LOCK. In
LINE-LOCK mode, without a synchronous generator, it synchronizes the video signal between
cameras. The Line-Lock synchronization is only used in the places of 60Hz (NTSC models) or 50Hz
(PAL models).
-INT: Internal synchronization
-LL: External line-lock synchronization
=> If you choose “LL”, you can adjust the phase your wish to set. Then press the mini-joystick. You
can adjust the phase you wish to set from 0 to 359.
C A M E R A I D
A B C D E F G H I J K L M
N
O P Q R S T U V W X Y Z
a b c d e f g h i j k l m
n o p q r s t u v w x y z
─ ·
0 1 2 3 4 5 6 7 8 9
← → C L R P O S E N D
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _
COLOR GAIN.
> LEVEL |++++++++| 8
SPECIAL
CAMERA ID OFF
> COLOR ADJ. <┘
SYNC. INT
MOTIION DET OFF
PRIVACY OFF
MIRROR OFF
SHARPNESS ON <┘
RESET
RETURN <┘
