Echo PPT-2100 - Manual (Page 35)

P
OWER
P
RUNER
O
PERATOR
'
S
M
ANUAL
13A
S
PECIFICATIONS
Specifications, descriptions and illustrative material in this literature are as accurate as known at the time of publication,
but are subject to change without notice. Illustrations may include optional equipment and accessories, and may not
include all standard equipment.
M O D E L P P T -2 1 0 0 P P T -2 4 0 0
L e n g th ( S ta n d a rd ) 2 .2 6 m (7 ft., 5 i n .) 2 .7 4 m ( 9 ft.)
L e n g th ( E xte n d e d ) 3 .4 1 m ( 1 1 ft., 2 .2 5 i n .) 3 .9 1 m ( 2 ft., 9 .7 5 i n .)
L e n g th w /e xte n s i o n 5 .0 0 m (1 6 ft., 5 i n .) 5 .4 9 m ( 1 8 ft.)
W i d th .2 2 m ( 8 .7 5 i n .)
H e i g h t .2 3 m ( 9 .0 i n .)
W e i g h t ( d ry) 7 .4 k g (1 6 .3 lb .) 7 .7 k g ( 1 6 .9 lb .)
E n g i n e Typ e A i r c o o le d , tw o -s tro k e , s i n g le c yli n d e r g a s o li n e e n g i n e
B o r e 3 2 .2 m m (1 .2 6 8 i n .) 3 4 .0 m m (1 .3 3 9 i n .)
S tro k e 2 6 .0 m m (1 .0 4 i n .) 2 6 .0 m m (1 .0 4 i n .)
D i s p la c e m e n t 2 1 .2 c c ( 1 .2 9 c u . i n .) 2 3 .6 c c (1 .4 4 c u . i n .)
E xh a u s t S ys te m S p a rk A rre s to r M u ffle r
C a rb u re to r D i a p h ra g m , w /p ri m e r b u lb
Ig n i ti o n S ys te m C D I (c a p a c i to r d i s c h a rg e i g n i ti o n )
S p a rk P lu g
N G K B P M -7 A G a p 0 .6 5 m m ( 0 .0 2 6
i n .)
N G K B P M -7 Y G a p 0 .6 5 m m ( 0 .0 2 6 i n .)
F u e l M i xe d ( G a s o li n e a n d Tw o -s tr o k e O i l)
F u e l/O i l R a ti o 5 0 :1 E C H O H i g h P e rfo rm a n c e , tw o -s tro k e a i r c o o le d e n g i n e o i l
G a s o li n e
8 9 O c ta n e u n le a d e d . D O N O T u s e fu e l c o n ta i n i n g m e th yl a lc o h o l,
m o re th a n 1 0 % e th yl a lc o h o l o r 1 5 % M T B E .
F u e l Ta n k C a p a c i ty 0 .4 li t. (1 4 .0 U S fl. o z.)
S ta rte r S ys te m A u to m a ti c R e c o i l S ta rte r
C lu tc h C e n tri fu g a l Typ e
S p r o c k e t Ty p e 6 to o th s p u r, 9 .5 3 m m ( 3 /8 " ) p i tc h
P o w e r Tra n s m i s s i o n S h a ft A s s e m b ly A lu m i n u m E xtru s i o n
G e a r C a s e R a ti o 1 .5 :1
O i li n g S ys te m A u to m a ti c
S a w C h a i n O i l C a p a c i ty 2 2 5 m l ( 7 .6 o z.)
H a n d le R i g h t h a n d g ri p w /th ro ttle tri g g e r a n d lo c k o u t
S h o u ld e r H a rn e s s S ta n d a rd
Id le S p e e d (R P M ) 2 6 0 0 - 3 1 0 0
W i d e O p e n T h r o ttle S p e e d (R P M ) 8 0 0 0 - 9 0 0 0 1 1 ,0 0 0 - 1 2 ,0 0 0
G u i d e B a r a n d S a w C h a i n (9 1 V S ) 2 5 4 m m (1 0 i n .) ;
9 .5 3 m m (3 /8 " ) p i tc h
3 0 5 m m ( 1 2 i n .) ;
9 .5 3 m m (3 /8 " ) p i tc h
