13
MODEL PPT-2100 PPT-2400
Length (Standard) 2286 mm (90.0 in.) 2743 mm (108.0 in.)
Length (Extended) 3410 mm (134.25 in.) 3886 mm (153.0 in.)
Width 222 mm (8.75 in.) 222 mm (8.75 in.)
Height 229 mm (9.0 in.) 229 mm (9.0 in.)
Weight (dry) 7.4 kg (16.3 lb.) 7.7 kg (16.9 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 32.2 mm (1.268 in.) 34.0 mm (1.339 in.)
Stroke 26.0 mm (1.04 in.) 26.0 mm (1.04 in.)
Displacement 21.2 cc (1.29 cu. in.) 23.6 cc (1.44 cu. in.)
Exhaust System Spark Arrestor Muffler
Carburetor Diaphragm, w/primer bulb
Ignition System CDI (capacitor discharge ignition)
Spark Plug
NGK BPM-7A
Gap 0.65 mm (0.026 in.)
NGK BPM-7Y
Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio 50:1 ECHO High Performance, two-stroke air cooled engine oil
Gasoline
89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
Oil 50:1 ECHO High Performance, two-stroke air cooled engine oil
Fuel Tank Capacity 0.4 lit. (14.0 US fl. oz.)
Starter System Automatic Recoil Starter
Clutch Centrifugal Type
Sprocket Type 6 tooth spur, 9.53 mm (3/8") pitch
Power Transmission Shaft Assembly Aluminum Extrusion
Gear Case Ratio 1.5:1
Oiling System Automatic
Saw Chain Oil Capacity 59 ml (2.0 oz.)
Handle Right hand grip w/throttle trigger and lockout
Shoulder Harness Standard
Idle Speed (RPM) 2600 - 3100
Wide Open Throttle Speed (RPM) 8000 - 9000 11,000 - 12,000
Guide Bar and Saw Chain (90SG) 254 mm (10 in.) ;
9.53 mm (3/8") pitch
305 mm (12 in.) ;
9.53 mm (3/8") pitch
S
PECIFICATIONS
Specifications, descriptions and illustrative material in this literature are as accurate as known at the time of publication, but
are subject to change without notice. Illustrations may include optional equipment and accessories, and may not include all
standard equipment.
