Evo Fitness FX20 - Manual (Page 7)

FX20 MOTORIZED TREADMILL
Visit us at: www.evofitness.com
7
PARTS LIST
NO. DESCRIPTION QTY. ORDER NO. NO. DESCRIPTION QTY. ORDER NO.
55
Elevation Support
Frame End Cap #1
2
20-55 82
M10 x 68mm Allen Bolt 1
20-82
56
Plastic Clamp -
Upper
2
20-56 83
Pivot Shaft 1
20-83
57
Plastic Clamp -
Bottom
2
20-57 84
Deck Wheel Bolt 2
20-84
58
Bracket 2
20-58 85
Fold Up Stopper 1
20-85
59
Elevation Support
Frame End Cap #2
2
20-59 86
Elevation Support Frame
Fixing Bolt
2
20-86
60
Deck Frame 1
20-60 87
6mm Washer 3
20-87
61
Elevation Motor 1
20-61 88
Washer 10
20-88
62
Elevation Motor Gear
Sleeve
1
20-62 89
10mm Washer 2
20-89
63
Gas Shock 1
20-63 90
M8 Nylon Nut 7
20-90
64
Deck Wheel 2
20-64 91
M10 Nylon Nut 2
20-91
65
PU Cushion 1
20-65 92
M10 Nut 1
20-92
66
20 x 40mm Washer 2
20-66 93
N/A
20-93
67
Driving Belt
Adjustment bolt
1
20-67 94
Gas Shock Fixing
Spacer
2
20-94
68
M16 Nylon Nut 1
20-68 95
Base Frame Rubber
Cushion - Front
4
20-95
69
Deck Rubber
Cushion Bolt
8
20-69 96
Elevation Control Board
Fixing Insert
6
20-96
70
M4 x 15mm Screw 27
20-70 97
Handlebar 1
20-97
71
Console Housing
Screw
10
20-71 98
Running Deck Cross
Brace 1
20-98
72
Plastic Fixing Insert 6
20-72 99
Running Deck Cross
Brace Foam
1 20-99
73
Side Rail Guider
Screw
12
20-73 100 M8 x 30mm Screw 4 20-100
74
Rubber Cushion
Screw
4
20-74 101 SPRING 1 20-101
75
Roller Adjustment
Bolt
3
20-75 102
TRANSPORTATION
WHEEL BRACKET
1 20-102
76
M6 x 15mm Screw 4
20-76
77
M8 x 18 Allen Bolt 6
20-77
78
M10 x 50mm Allen
Bolt
4
20-78
79
Transportation Wheel
Bolt
2
20-79
80
Elevation Motor
Fixing Bolt
1
20-80
81
M10 x 63mm Bolt 1
20-81
