FX20 MOTORIZED TREADMILL
Visit us at: www.evofitness.com
5
HARDWARE COMPARISON CHART
Hardware chart:
For your convenience, we have identified the hardware used in the assembly of this product. This chart is provided to
help you identify those items that may be unfamiliar to you.
NO. DESCRIPTION
QTY.
70
M4 x 15mm Screw
19
76
M6 X 15mm Screw
2
77
M8 x 18mm Allen Bolt
2
78
M8 x 50mm Allen Bolt
2
88 Washer
4
100
M8 x 30mm Screw
2
A
Allen Key Tool
1
B Screw
Driver
Tool
1
C Allen
Wrench
Tool
1
88
76
77
100
78
70
A
B
C
MILIMETERS
