FX20 MOTORIZED TREADMILL
Visit us at: www.evofitness.com
6
PARTS LIST
NO. DESCRIPTION
QTY.
ORDER NO.
NO. DESCRIPTION
QTY.
ORDER NO.
1
Computer Insert
1
20-01
28
Fold Up Support Bushing
2
20-28
2
Console Housing -
Upper
1
20-02
29
Fold Up Support Insert
1
20-29
3
Console Housing -
Bottom
1
20-03
30
Nut 1
20-30
4
Safety Key
1
20-04
31
Spacer 1
20-31
5
EKG Pulse Sensor
2
20-05
32
Foot Up Locker
1
20-32
6
Front Handlebar
1
20-06
33
Base Frame Rubber
Cushion - Rear
2
20-33
7
Handlebar Cover -
Left #1
1
20-07
34
Transportation Wheel
2
20-34
8
Handlebar Cover -
Left #2
1
20-08
35
Console Plate
1
20-35
9
Handlebar Cover -
Right #2
1
20-09
36
Motor Hood
1
20-36
10
Handlebar Cover -
Right #1
1
20-10
37
Side Rail
2
20-37
11
Handlebar Grip
2
20-11
38
Deck End Cap - Right
1
20-38
12
Handlebar End Cap
2
20-12
39
Deck End Cap - Left
1
20-39
13
EKG Pulse Wire
2
20-13
40
Motor Bottom Cover
1
20-40
14
Motion Control
Sensor
2
20-14
41
Motor Hood Side Cover -
Right
1
20-41
15
Upright - Left
1
20-15
42
Motor Hood Side Cover -
Left
1
20F-42
16
Upright - Right
1
20-16
43
Front Roller
1
20-43
17
Upright Base Cover -
Left #1
1
20-17
44
Rear Roller
1
20-44
18
Upright Base Cover -
Left #2
1
20-18
45
Running Belt
1
20-45
19
Upright Base Cover -
Right #2
1
20-19
46
Motor Holder
1
20-46
20
Upright Base Cover -
Right #1
1
20-20
47
Driving DC Motor
1
20-47
21
Upright Base Cover-
Upper
2
20-21
48
Driving Belt
1
20-48
22
Base Frame
1
20-22
49
Elevation Control Board
1
20-49
23
Fold Up Support
1
20-23
50
Motor Control Board
1
20-50
24
Power Plate
1
20-24
51
Running Deck
1
20-51
25
Power Plate Plastic
Frame
1
20-25
52
Side Rail Guider
6
20-52
26
Base Frame Tube
End Cap - Front
2
20-26
53
Running Deck Rubber
Cushion
8
20-53
27
Base Frame Tube
End Cap - Rear
2
20-27
54
Elevation Support Frame
1
20-54
