Installing a VHSIM
2-12 Installation
7. Place the VHSIM2-A6DP behind the device faceplate as shown back in Figure 2-6 .
8. Insert the connectors of the VHSIM2-A6DP into the host device connector pins on the device.
9. Press down firmly on the back of the VHSIM2-A6DP until the pins slide all the way into the
connector holes.
10. Secure the VHSIM2-A6DP to the faceplate using the screws saved in step 5 .
11. Secure the VHSIM2-A6DP to the standoffs using the screws saved in step 6 .
12. Reattach the chassis cover to the device, reconnect the power cord, and reconnect the device to
your network.
13. Refer to Chapter 3 for instructions on configuring the VHSIM2-A6DP using Local
Management.
CAUTION: In step 8 , ensure that the standoffs on the device align with the standoff
screw holes on the VHSIM2-A6DP to prevent bending the pins.
ELECTRICAL HAZARD: Ensure that the chassis cover is in place before reconnecting
the power cord.
