Emerson 20" Color Television 6420FE - Manual (Page 48)

20040405 13-5 L2401EL
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC3331(T)-AANP or 2SC3331TZ
TRANSISTOR 2SC3331(U)-AANP or 2SC3331UZ
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q361 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC3331(T)-AANP or 2SC3331TZ
TRANSISTOR 2SC3331(U)-AANP or 2SC3331UZ
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q571# TRANSISTOR TT2140LS-YB11 or QQZZ00TT2140
# TRANSISTOR 2SC5885000RF QQZZ02SC5885
Q572 TRANSISTOR 2SC1627Y-TPE2 QQSY02SC1627
Q601# MOS FET 2SK3563 or QFWZ02SK3563
# MOS FET 2SK2662 QF5Z02SK2662
Q602# TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
# TRANSISTOR 2SC2120-Y(TPE2) QQSY02SC2120
Q631 TRANSISTOR 2SA1175(F) or QQSF02SA1175
TRANSISTOR KTA1267(GR) or NQS10KTA1267
TRANSISTOR KTA1266(GR) or NQS40KTA1266
TRANSISTOR 2SA1318(T)-AANP or 2SA1318TZ
TRANSISTOR 2SA1318(U)-AANP or 2SA1318UZ
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
Q652# TRANSISTOR 2SC2785(F) or QQSF02SC2785
# TRANSISTOR 2SC2785(H) or QQSH02SC2785
# TRANSISTOR 2SC2785(J) or QQSJ02SC2785
# TRANSISTOR KTC3199(GR) or NQS10KTC3199
# TRANSISTOR KTC3198(GR) or NQS40KTC3198
# TRANSISTOR 2SC3331(T)-AANP or 2SC3331TZ
# TRANSISTOR 2SC3331(U)-AANP or 2SC3331UZ
# TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q672# TRANSISTOR 2SA1175(F) or QQSF02SA1175
# TRANSISTOR KTA1267(GR) or NQS10KTA1267
# TRANSISTOR KTA1266(GR) or NQS40KTA1266
# TRANSISTOR 2SA1318(T)-AANP or 2SA1318TZ
# TRANSISTOR 2SA1318(U)-AANP or 2SA1318UZ
# TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
Q673 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC3331(T)-AANP or 2SC3331TZ
TRANSISTOR 2SC3331(U)-AANP or 2SC3331UZ
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q674 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC3331(T)-AANP or 2SC3331TZ
TRANSISTOR 2SC3331(U)-AANP or 2SC3331UZ
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q681 TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
TRANSISTOR 2SC2120-Y(TPE2) QQSY02SC2120
Q682 TRANSISTOR 2SD400(E) or QQUE002SD400
TRANSISTOR 2SD400(F) or QQUF002SD400
TRANSISTOR KTC3205(Y) or NQSY0KTC3205
TRANSISTOR KTC3205OAT NQS00KTC3205
Ref. No. Description Part No.
Q696 RES. BUILT-IN TRANSISTOR BA1F4M-T or QQSZ00BA1F4M
RES. BUILT-IN TRANSISTOR KRC103M NQSZ0KRC103M
Q801 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC3331(T)-AANP or 2SC3331TZ
TRANSISTOR 2SC3331(U)-AANP or 2SC3331UZ
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q811 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC3331(T)-AANP or 2SC3331TZ
TRANSISTOR 2SC3331(U)-AANP or 2SC3331UZ
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
RESISTORS
R12 PCB JUMPER D0.6-P5.0 JW5.0T
R31 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJB5Z0222
R32 CARBON RES. 1/4W J 390 Ω RCX4JATZ0391
R33 CHIP RES.(1608) 1/10W J 270 Ω RRXAJB5Z0271
R34 CHIP RES.(1608) 1/10W J 220 Ω RRXAJB5Z0221
R37 CHIP RES.(1608) 1/10W J 220 Ω RRXAJB5Z0221
R38 CHIP RES.(1608) 1/10W J 12k Ω RRXAJB5Z0123
R39 CHIP RES.(1608) 1/10W J 27k Ω RRXAJB5Z0273
R44 CHIP RES.(1608) 1/10W J 100 Ω RRXAJB5Z0101
R51 CHIP RES.(1608) 1/10W J 220k Ω RRXAJB5Z0224
R52 CARBON RES. 1/4W J 220k Ω RCX4JATZ0224
R54 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R101 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R102 CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJB5Z0152
R103 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJB5Z0222
R104 CHIP RES.(1608) 1/10W J 2.7k Ω RRXAJB5Z0272
R105 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJB5Z0472
R106 CHIP RES.(1608) 1/10W J 8.2k Ω RRXAJB5Z0822
R108 CHIP RES.(1608) 1/10W J 10k Ω RRXAJB5Z0103
R109 CHIP RES.(1608) 1/10W J 10k Ω RRXAJB5Z0103
R111 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R112 CHIP RES.(1608) 1/10W J 10k Ω RRXAJB5Z0103
R113 CHIP RES.(1608) 1/10W J 270k Ω RRXAJB5Z0274
R114 CHIP RES.(1608) 1/10W J 1k Ω RRXAJB5Z0102
R116 CHIP RES. 1/10W J 0 Ω RRXAJB5Z0000
R121 CHIP RES.(1608) 1/10W J 100 Ω RRXAJB5Z0101
R122 CHIP RES.(1608) 1/10W J 100 Ω RRXAJB5Z0101
R123 CHIP RES.(1608) 1/10W J 1k Ω RRXAJB5Z0102
R131 CHIP RES.(1608) 1/10W J 470 Ω RRXAJB5Z0471
R133 CHIP RES. 1/10W J 0 Ω RRXAJB5Z0000
R134 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJB5Z0472
R135 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJB5Z0222
R136 CHIP RES.(1608) 1/10W J 100k Ω RRXAJB5Z0104
R137 CHIP RES.(1608) 1/10W J 100 Ω RRXAJB5Z0101
R138 CHIP RES.(1608) 1/10W J 220k Ω RRXAJB5Z0224
R139 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R140 CHIP RES.(1608) 1/10W J 1k Ω RRXAJB5Z0102
R141 CHIP RES. 1/10W J 0 Ω RRXAJB5Z0000
R150 CHIP RES. 1/10W J 0 Ω RRXAJB5Z0000
R153 CHIP RES.(1608) 1/10W J 100 Ω RRXAJB5Z0101
R154 CHIP RES.(1608) 1/10W J 100 Ω RRXAJB5Z0101
Ref. No. Description Part No.
