Emerson 20" Color Television 6420FE User Manual
Page 45
20040405
13-2
L2401EL
ELECTROLYTIC CAP. 1000
µF/10V M
CE1AMASDL102
C351
CERAMIC CAP.(AX) B K 100pF/50V
CCA1JKT0B101
C352
CERAMIC CAP.(AX) B K 100pF/50V
CCA1JKT0B101
C353
ELECTROLYTIC CAP. 1
µF/50V M or
CE1JMASTL1R0
ELECTROLYTIC CAP. 1
µF/50V M or
CE1JMASDL1R0
ELECTROLYTIC CAP. 1
µF/50V M or
CE1JMASDL010
ELECTROLYTIC CAP. 1
µF/50V M
CE1JMASTL010
C401
ELECTROLYTIC CAP. 3.3
µF/50V M or
CE1JMASTL3R3
ELECTROLYTIC CAP. 3.3
µF/50V M
CE1JMASDL3R3
C402
ELECTROLYTIC CAP. 3.3
µF/50V M or
CE1JMASTL3R3
ELECTROLYTIC CAP. 3.3
µF/50V M
CE1JMASDL3R3
C403
CERAMIC CAP.(AX) F Z 0.1
µF/50V or
CA1J104TU014
CERAMIC CAP.(AX) F Z 0.1
µF/50V
CCA1JZT0F104
C404
CERAMIC CAP.(AX) B K 0.022
µF/50V
CA1J223TU011
C405
CHIP CERAMIC CAP. F Z 0.1
µF/25V
CHD1EZB0F104
C406
CHIP CERAMIC CAP. B K 0.033
µF/25V
CHD1EKB0B333
C411
ELECTROLYTIC CAP. 4.7
µF/50V M or
CE1JMASTL4R7
ELECTROLYTIC CAP. 4.7
µF/50V M
CE1JMASDL4R7
C413
ELECTROLYTIC CAP. 100
µF/10V M or
CE1AMASTL101
ELECTROLYTIC CAP. 100
µF/10V M
CE1AMASDL101
C414
ELECTROLYTIC CAP. 2.2
µF/50V M or
CE1JMASTL2R2
ELECTROLYTIC CAP. 2.2
µF/50V M
CE1JMASDL2R2
C415
CHIP CERAMIC CAP. CH J 150pF/50V
CHD1JJBCH151
C416
CHIP CERAMIC CAP. CH J 150pF/50V
CHD1JJBCH151
C417
ELECTROLYTIC CAP. 2.2
µF/50V M or
CE1JMASTL2R2
ELECTROLYTIC CAP. 2.2
µF/50V M
CE1JMASDL2R2
C421
ELECTROLYTIC CAP. 4.7
µF/50V M or
CE1JMASTL4R7
ELECTROLYTIC CAP. 4.7
µF/50V M
CE1JMASDL4R7
C422
ELECTROLYTIC CAP. 0.47
µF/50V M or
CE1JMASTLR47
ELECTROLYTIC CAP. 0.47
µF/50V M
CE1JMASDLR47
C423
CHIP CERAMIC CAP. B K 5600pF/50V
CHD1JKB0B562
C426
ELECTROLYTIC CAP. 4.7
µF/50V M or
CE1JMASTL4R7
ELECTROLYTIC CAP. 4.7
µF/50V M
CE1JMASDL4R7
C427
ELECTROLYTIC CAP. 0.47
µF/50V M or
CE1JMASTLR47
ELECTROLYTIC CAP. 0.47
µF/50V M
CE1JMASDLR47
C428
CERAMIC CAP.(AX) X K 5600pF/16V
CDA1CKT0X562
C441
ELECTROLYTIC CAP. 10
µF/50V M or
CE1JMASTL100
ELECTROLYTIC CAP. 10
µF/50V M
CE1JMASDL100
C442
ELECTROLYTIC CAP. 2.2
µF/50V M or
CE1JMASTL2R2
ELECTROLYTIC CAP. 2.2
µF/50V M
CE1JMASDL2R2
C444
ELECTROLYTIC CAP. 0.33
µF/50V M or
CE1JMASTLR33
ELECTROLYTIC CAP. 0.33
µF/50V M
CE1JMASDLR33
C445
FILM CAP.(P) 0.1
µF/50V J or
CMA1JJS00104
FILM CAP.(P) 0.1
µF/50V J
CA1J104MS029
C446
FILM CAP.(P) 0.1
µF/50V J or
CMA1JJS00104
FILM CAP.(P) 0.1
µF/50V J
CA1J104MS029
C448
ELECTROLYTIC CAP. 2.2
µF/50V M or
CE1JMASTL2R2
ELECTROLYTIC CAP. 2.2
µF/50V M
CE1JMASDL2R2
C501
FILM CAP.(P) 0.1
µF/50V J or
CMA1JJS00104
FILM CAP.(P) 0.1
µF/50V J
CA1J104MS029
C503
ELECTROLYTIC CAP. 47
µF/35V M or
CE1GMASTL470
ELECTROLYTIC CAP. 47
µF/35V M
CE1GMASDL470
C504
ELECTROLYTIC CAP. 1
µF/50V M LL or
CE1JMASLL1R0
ELECTROLYTIC CAP. 1
µF/50V LL
CE1JMASLH1R0
C505
ELECTROLYTIC CAP. 1000
µF/25V M or
CE1EMZNTL102
ELECTROLYTIC CAP. 1000
µF/25V M or
CE1EMZPDL102
ELECTROLYTIC CAP. 1000
µF/25V M
CE1EMZADL102
C506
ELECTROLYTIC CAP. 470
µF/35V M(VR) or
CE1GMZNTL471
ELECTROLYTIC CAP. 470
µF/35V M or
CE1GMZADL471
ELECTROLYTIC CAP. 470
µF/35V M or
CE1GMZNDL471
ELECTROLYTIC CAP. 470
µF/35V M
CE1GMZPDL471
Ref. No.
Description
Part No.
C507
FILM CAP.(P) 0.047
µF/50V J or
CMA1JJS00473
FILM CAP.(P) 0.047
µF/50V J
CA1J473MS029
C520#
ELECTROLYTIC CAP. 4.7
µF/50V M or
CE1JMASTL4R7
#
ELECTROLYTIC CAP. 4.7
µF/50V M
CE1JMASDL4R7
C566
CERAMIC CAP. LB 1200pF/2KV or
CA3D122KG004
CERAMIC CAP. BN 1200pF/2KV or
CCD3DKA0B122
CERAMIC CAP. 1200pF/2KV
CA3D122PAN04
C571#
P.P.CAP 0.27
µF/200 J or
CA2D274VC012
#
PP CAP. 0.27
µF/250V J or
CT2E274MS041
#
METALLIZED FILM CAP. 0.27
µF/200V J or
CT2D274F7001
#
METALLIZED FILM CAP. 0.27
µF/200V J
CT2D274F7003
C574#
ELECTROLYTIC CAP. 4.7
µF/250V M or
CE2EMASTL4R7
#
ELECTROLYTIC CAP. 4.7
µF/250V M
CE2EMASDL4R7
C577
ELECTROLYTIC CAP. 47
µF/35V M or
CE1GMASTL470
ELECTROLYTIC CAP. 47
µF/35V M
CE1GMASDL470
C578
FILM CAP.(P) 0.01
µF/50V J or
CMA1JJS00103
FILM CAP.(P) 0.01
µF/50V J
CA1J103MS029
C580#
PP CAP. 0.0082
µF/1.6KV J or
CT3C822MS039
#
P.P. CAP 0.0082
µF/1.6K J or
CA3C822VC011
#
METALLIZED FILM CAP. 0.0082
µF/1.6KV J
CT3C822F7004
C582#
PCB JUMPER D0.6-P10.0
JW10.0T
C584#
ELECTROLYTIC CAP. 1
µF/160V M or
CE2CMASTL1R0
#
ELECTROLYTIC CAP. 1
µF/160V M
CE2CMASDL1R0
C588#
ELECTROLYTIC CAP. 47
µF/160V M or
CE2CMZPTL470
#
ELECTROLYTIC CAP. 47
µF/160V M W/F or
CE2CMZNDL470
#
ELECTROLYTIC CAP. 47
µF/160V M W/F
CE2CMZPDL470
C594#
ELECTROLYTIC CAP. 10
µF/50V M or
CE1JMASTL100
#
ELECTROLYTIC CAP. 10
µF/50V M
CE1JMASDL100
C601#
METALLIZED FILM CAP. 0.1
µF/250V or
CT2E104MS037
#
FILM CAP.(MP) 0.1
µF/250V K or
CT2E104DC011
#
METALLIZED FILM CAP. 0.1
µF/275V K
CT2E104HJE06
C605
CERAMIC CAP. F Z 0.01
µF/500V or
CCD2JZP0F103
CERAMIC CAP. 0.01
µF/AC250V or
CCD2EZA0F103
CERAMIC CAP. E Z 0.01
µF/500V
CCD2JZP0E103
C606
CERAMIC CAP. F Z 0.01
µF/500V or
CCD2JZP0F103
CERAMIC CAP. 0.01
µF/AC250V or
CCD2EZA0F103
CERAMIC CAP. E Z 0.01
µF/500V
CCD2JZP0E103
C609
CERAMIC CAP. LB 680pF/2K or
CA3D681KG004
CERAMIC CAP. BN 680pF/2KV or
CCD3DKA0B681
CERAMIC CAP. 680pF/2KV or
CA3D681PAN04
CERAMIC CAP. RB 680pF/2KV
CA3D681TE006
C610#
ELECTROLYTIC CAP. 220
µF/200V or
CA2D221NC088
#
ELECTROLYTIC CAP. 220
µF/200V SL X
CA2D221S6003
C611
FILM CAP.(P) 0.0068
µF/50V J or
CMA1JJS00682
FILM CAP.(P) 0.0068
µF/50V J
CA1J682MS029
C616
FILM CAP.(P) 0.068
µF/50V J or
CMA1JJS00683
FILM CAP.(P) 0.068
µF/50V J
CA1J683MS029
If C642 is 0.01
µF, then C643 is 0.01µF.
C642#
SAFETY CAP. 10000pF/250V or
CCG2EMA0F103
#
SAFETY CAP. F M 0.01
µF/250V or
CCG2EMP0F103
#
CERAMIC CAP. 0.01
µF F CS
CCG2HMN0F103
C643#
SAFETY CAP. 10000pF/250V or
CCG2EMA0F103
#
SAFETY CAP. F M 0.01
µF/250V or
CCG2EMP0F103
#
CERAMIC CAP. 0.01
µF F CS
CCG2HMN0F103
If C643 is 4700pF, then JS642(PCB JUMPER) is used.
C643#
SAFETY CAP. 4700pF/250V KX
CA2E472MR050
JS642
PCB JUMPER D0.6-P10.0
JW10.0T
C654#
ELECTROLYTIC CAP. 1
µF/50V M or
CE1JMASTL1R0
#
ELECTROLYTIC CAP. 1
µF/50V M or
CE1JMASDL1R0
#
ELECTROLYTIC CAP. 1
µF/50V M or
CE1JMASDL010
#
ELECTROLYTIC CAP. 1
µF/50V M
CE1JMASTL010
Ref. No.
Description
Part No.
