Setting up
Name and function of each part
LINK
ACT
Serial port
Used to control the external equipment
via the network.
PowER indicator
This lights up red when the network
function is set ON in the projector
menu.
LaN port
Connecting the LAN cable.
Connector plug
Connecting to the terminal on the pro-
jector.
Mounting screws
Mount by using a coin etc.
LINK indicator
This lights up red when the network unit is
connected to the network correctly.
aCT indicator
This turns on and off with green when
sending or receiving of data
(Top View)
(Bottom View)
