12
CONNECTING PROJECTOR
S–VIDEO
R – AUDIO 4 – L
VIDEO/Y – Cb/Pb – Cr/Pr
RESET
CONTROL PORT
USB
AUDIO 1
AUDIO 2
INPUT 1
INPUT 2 / OUT
INPUT 3
INPUT 4
R/C JACK
(MONO)
R – AUDIO 3 – L
VIDEO/Y – Cb/Pb – Cr/Pr (MONO)
TERMINALS OF PROJECTOR
When controlling computer
with Remote Control Unit of
this projector, connect mouse
port of your personal computer
to this connector. (Refer to
P13.)
Connect S-VIDEO output
from video equipment to this
jack. (Refer to P14.)
Connect an audio output
from video equipment to
these jacks.
(Refer to P14.)
CONTROL PORT CONNECTOR
COMPUTER AUDIO INPUT 2/
AUDIO MONITOR OUTPUT JACK
AUDIO INPUT JACKS
(INPUT 3 and INPUT 4)
VIDEO INPUT JACKS
(INPUT 3 and INPUT 4)
S-VIDEO INPUT JACK
Connect composite video
output from video equipment
to VIDEO/Y jack or connect
component video outputs to
VIDEO/Y, Cb/Pb and Cr/Pr
jacks. (Refer to P14.)
This terminal is switchable and can
be used as computer input or monitor
output. Set the terminal up as either
Computer input or Monitor output
properly before using this terminal.
Refer to P13, P23.)
Note; This terminal outputs from
COMPUTER INPUT 1 jacks only.
COMPUTER INPUT 2/MONITOR OUTPUT
(ANALOG HDB 15-pin) TERMINAL
This projector has input and output terminals on its back for connecting computers and video equipment. Refer to figures on
pages 12 to 14 and connect properly.
This projector uses a micro processor
to control this unit, and occasionally,
this micro processor may malfunction
and need to be reset. This can be
done by pressing RESET button with a
pen, which will shut down and restart
unit. Do not use RESET function
excessively.
RESET BUTTON
When controlling computer
with Remote Control Unit of
this projector, connect USB
terminal of your personal
computer to this terminal.
(Refer to P13.)
USB CONNECTOR (Series B)
When using Wired/Wireless
Remote Control Unit as Wired
Remote Control, Connect
Wired Remote Control Unit to
this jack with Remote Control
Cable (supplied).
R/C JACK
Connect an audio output
(stereo) from computer to
this jack.
(Refer to P13.)
COMPUTER AUDIO
INPUT 1 JACK
This terminal is switchable and can be
used as computer audio input 2 or
audio monitor output (variable).
Set the terminal up as either
Computer audio input 2 or Audio
Monitor output properly before using
this terminal. (Refer to P13, P23.)
COMPUTER INPUT 1
(ANALOG HDB 15-pin)
TERMINAL
Connect computer
output to this terminal.
(Refer to P13.)
Connect External Speaker to these
terminals.
(Refer to P13 and P14.)
EXTERNAL SPEAKER TERMINALS
