7
Setup
WARNING
The power button on the front panel DOES NOT turn off the AC
power. To remove power from server, you must unplug the AC
power cord(s) from the wall outlet or the chassis.
3.1 Installing the Server Board
Installing the server board consists of the following steps:
1. Removing the cover.
2. Removing the riser card &Fan &pole
3. Mounting the server board in the chassis.
4. Cabling the server board to the other chassis components.
5. Adding processors and memory to the server board.
6. Adding the riser card &Fan &pole
8. Replacing the cover.
Removing the Cover
To remove the top cover of the system:
1. Press the keystroke and pull the cover back and remove it from
the chassis.(PIC 3.1)
2. Set chassis cover aside and away from immediate work area.
