7. CALL / MATRIX MONITOR SETUP
Enter the call and matrix monitor setup menu by pressing the CALL key:
Define the following settings in the CALL menu:
Press ENTER to select the respective monitor and the selection options:
(1) SEQ:
“ON" activates the monitor’s sequence mode (automatic sequential switch).
(2) OSD:
“ON" activates the monitor’s status display including camera number,
monitor number and active alarms for this monitor.
(3) CAMERA:
Select the camera to be displayed with the channel keys 1~9 (EDR920) resp.
1~16 (EDR1640).
