POWXG6007
Copyright © 2011 VARO P a g e | 9
YOUR GASOLINE LAWNMOWER IS EQUIPPED WITH A CENTRAL HEIGHT
ADJUSTMENT LEVER OFFERING 10 HEIGHT POSITIONS
Fig 9
1. Stop mower and disconnect spark
plug cable before changing mower
cutting height.
2. The central height adjustment
offers you 10 different height
positions.
3. To change the height of cut, squeeze
adjuster lever toward the wheel,
moving up or down to selected
height. (Fig.9)
4. All wheels will be in the same height
of cut.
7 MAINTENANCE INSTRUCTIONS
SPARK PLUG
Use only original replacement spark plug. For best results, replace the spark plug every 100
hours of use.
1.
Stop the engine and remove the spark plug wire.
2. Remove spark plug
3. Screw the replacement spark plug into the engine and tighten to 25-30 Nm torque and
replace spark plug wire.
4. Spark plug gap. 0.6 – 0.7mm.
CAUTION: Do not over-tighten the spark plug as engine damage may occur.
8 LUBRICATION INSTRUCTIONS
CAUTION: Disconnect spark plug wire before servicing.
1. WHEELS-Lubricate the ball bearings in each wheel at least once a season with a light oil.
2. ENGINE-Follow engine manual for lubrication instructions.
3. BLADE CONTROL-Lubricate the pivot points on the blade control handle and the brake
cable at least once a season with light oil. The blade control must operate freely
directions.
9 CLEANING
CAUTION: Do not hose engine. Water can damage engine or contaminate
the fuel system.
1. Wipe deck with cloth.
2. Hose under deck by tilting the mower so that the spark plug is up.
9.1 Engine air cleaner
CAUTION: Do not allow dirt or dust to clog the air filter foam element.
