POWXG6007

EN

Copyright © 2011 VARO

P a g e

| 11

www.varo.com

Fig 11

Before reassembling the blade and the blade adapter to the unit, lubricate the engine
crankshaft and the inner surface of the blade adapter with light oil. Install the blade adapter on
the crankshaft with the "star" away from the engine. Refer to figure 11. Place the blade with
the part number facing away from the adapter. Align the washer over the blade and insert the
hex bolt. Tighten the hex bolt to the torque listed below:

9.3

Blade mounting torque

Center Bolt 40Nm.min, 54Nm.max. To insure safe operation of your unit. ALL nuts and bolts
must be checked periodically for correct tightness.
After prolonged use, especially in sandy soil conditions, the blade will become worn and lose
some of the original shape. Cutting efficiently will be reduced and the blade should be
replaced. Replace with an approved factory replacement blade only. Possible damage
resulting from blade unbalance condition is not the responsibility of the manufacturer.

9.4

Engine

Refer to the separate engine manual for engine maintenance instructions.
Maintain engine oil as instructed in the separate engine manual packed with your unit. Read
and follow instructions carefully.
Service air cleaner as per separate engine manual under normal conditions. Clean every few
hours under extremely dusty conditions. Poor engine performance and flooding usually
indicates that the air cleaner should be serviced.
To service the air cleaner, refer to the separate engine manual packed with your unit.
The spark plug should be cleaned and the gap reset once a season. Spark plug replacement
is recommended at the start of each mowing season; check engine manual for correct plug
type and gap specifications.
Clean the engine regularly with a cloth or brush. Keep the cooling system (blower housing
area) clean to permit proper air circulation which is essential to engine performance and life.
Be certain to remove all grass, dirt and combustible debris from muffler area.

10 STORAGE INSTRUCTIONS (OFF SEASON)

The following steps should be taken to prepare lawn mower for storage.
1.

Following the final cut of the season allow the fuel tank to run dry.

2.

Clean and lubricate mower thoroughly as described in the lubrication instructions.

3.

Refer to engine manual for correct engine storage instructions.

4.

Lightly coat mower's cutting blade with chassis grease to prevent rusting.

5.

Store mower in a dry, clean area.

NOTE:

Blade

Hex Bolt

Washer

Blade Adapter

Feather Key
