POWAIR0109 EN
Copyright © 2014 VARO P a g e | 5 www.varo.com
 Keep fluid output as small as possible to the extent that the job will not be hindered. It
will lead to better finishing with fine atomization.
 Set the spray distance from the gun to the workpiece as near as possible within the
range of 150 - 200mm.
 The gun should be held so that it is perpendicular to the surface of the workpiece at
all times. Then the gun should move in a and horizontal line. Arcing the gun causes
uneven painting.
6 MAINTENANCE
Turn off air and coating materials to the gun and release pressure by
triggering the gun before disassembling,gleaning or servicing.
Pay attention when disassembling spray gun since you must touch sharp
parts.
Do not disassemble without receiving enough knowledge and education.
 Pour remaining paint into another container and then clean paint passages and air
cap. Spray a small amount of thinner to clean paint passages. Incomplete cleaning
will cause adverse pattern shape and particles. Clean fully and promptly two-
component paint after use.
 Clean other sections with attached brush soaked with thinner and waste cloth.

Clean paint passages fully before disassembly.

Remove fluid nozzle after removing fluid needle set or while keeping fluid needle
pulled, in order to protect seat section.

Turn Spread adj. Knob counterclockwise to fully open And then tighten Spread adj.
guide into gun body.
Never immerse the whole gun into liquid such as thinner.
Never damage holes of air cap, fluid nozzle fluid needle.
7 STORING
 When not using spray gun, turn the fluid adjustment knob counter-clockwise to open
which will reduce spring tension on needle fluid tip.
 Spray gun MUST BE well cleaned and lightly lubricated.
8 TECHNICAL DATA
POWAIR0109
Air inlet
¼”
Type of feed Gravity
Standard diameter of nozzle 1.7mm
