Casio LK-73 - Manual (Page 16)

E-47
Keyboard Settings
With split you can assign two different tones (a main tone and
a split tone) to either end of the keyboard, which lets you play
one tone with your left hand and another tone with your right
hand. For example, you could select STRINGS as the main
(high range) tone and PIZZICATO as the split (low range)
tone, putting an entire string ensemble at your fingertips.
Split also lets you specify the split point, which is the location
on the keyboard where the changeover between the two tones
occurs.
1.
First select the main tone.
Example:
To select “048 STRINGS 1” as the main tone,
press the TONE button and then use the number
buttons or the [+] and [–] buttons to input 0, 4
and then 8.
2.
Press the SPLIT button.
1 Lit
3.
Select the split tone.
Example:
To select “045 PIZZICATO STR” as the split
tone, use the number buttons or the [+] and [–]
buttons to input 0, 4 and then 5.
4.
Specify the split point. While holding down the
SPLIT button, press the keyboard where you
want the leftmost key of the high end range to
be.
Example:
To specify G3 as the split point, press the G3 key.
5.
Now try playing something on the keyboard.
Š Every key from F #
3 and below is assigned the
PIZZICATO tone, while every key from G3 and
above is assigned the STRINGS tone.
6.
Press the SPLIT button again to unsplit the
keyboard and return it to normal.
SPLIT
Using Split
To split the keyboard
641A-E-049A
