CHAPTER 5 INTERFACE
4
Function available for RS232 or PRINTER output, please refer to section 7 and 8
below.
5-1 TOTALISING
Œ
Press the
Z
key until the unit weight displays
followed by
pressing key
1
WEIGHT
UNIT WEIGHT
QUANTITY
- - - - -
- - - - - -
WEIGHT
UNIT WEIGHT
QUANTITY
•
Press the
1
key.
WEIGHT
UNIT WEIGHT
QUANTITY
X
Use the number 0 , 1 or 2 key to select 0, 1, or 2
0
⇒
Press
M+
key and the window display will show the totalised value.
After 3 seconds, the scale will return to counting mode.
1
⇒
Press
M+
key and the window display will show the totalised value.
Press
CE
key and the scale will return to counting mode.
2
⇒
Press
M+
key and the display window will not show the totalised
value as the buzzer will beep.
Press the
.
key to exit the setting mode and the scale will return to counting mode.
