Table 6. award post code – EVGA 121-BL-E756 User Manual
Page 64
Configuring the BIOS
65
Appendix A. POST Codes for the EVGA
X58 SLI Micro Motherboard
This section provides the Award POST Codes (Table 6) for the EVGA X58
SLI Micro Motherboard during system boot up.
The POST Codes are displayed on the Debug LED readout located directly
onboard the motherboard.
This Debug LED will also display current CPU temperatures after the system
has fully booted into the Operating System.
Table 6.
Award POST Code
Award POST Codes
Code
Name
Description
01 Reserved
02
Jumps to E000
segment
Execution of POST routines in E000
03
Early SuperIO
Init Early Initialized the super IO
04 Reserved
05
Blank video
Reset Video controller
06 Reserved
07
Init KBC
Keyboard controller init
08
KB test
Test the Keyboard
09 Reserved
Debug LED with CPU
Temperature Monitor
