Strap Shortening Instructions
Your wristwatch strap may be shortened in two ways.
1. At the buckle
Unlock the safety cover (if applicable) and open the buckle. The
strap is held in position by a spring bar. The spring bar can be
compressed with a pointed tool to enable shortening of the strap.
Move the strap to the desired position and allow the spring bar to
lock into place.
2. At the strap
Shortening of the strap can also be achieved by removing segments.
Open the buckle and remove the spring bar as described in part 1.
Place the wristwatch on a soft surface with the dial facing
downward. The segments that can be removed are marked with an
arrow. Push a pointed tool into the opening on the backside of the
strap and push the bolt out of the strap in the direction of the arrow.
Pull out the bolt (you may need to use tweezers).
The strap can now be disassembled.
Remove as many segments as necessary in the described fashion
and reassemble the strap by pushing the bolt inwards in the opposite
direction of the arrow. Reassemble the buckle with the spring bar.
Replacement of battery (SR626SW)
Battery replacements must be performed by an expert to avoid
damaging the case or gaskets.
Water resistance
Water resistant up to 3 bar. The bar value specifies the atmospheric
overpressure which is applied during testing (DIN 8310).
