For uk use only for europe use only, Terminal block – Electrolux EOG 10000 User Manual
Page 23

electrolux 23
Connection Min. size
Cable /
Fuse
via
Cable/flex
flex type
• 13 A socket 0.75 mm
2
3 core
13 A
outlet
butyl
min.
• 13 A
insulated
spurbox
• Cooker
0.75 mm
2
PVC/PVC 13 A
Control
twin and
Circuit
earth
For Uk use only
For Europe use only
Min. size Cable/
Cable / flex type
Fuse
flex
0.75 mm
2
H05 RR-F
13 A
than 60°C above the ambient tempera-
ture.
Before the oven is connected, check that
the main fuse and the domestic installa-
tion can support the load and that the
power supply is properly earthed.
The manufacturer disclaims any
responsibility should these safety
measures not be carried out.
Terminal block
The oven is fitted with an easily accessible
terminal block which is designed to
operate with a single-phase power
supply of 230 V.
Letter L
-
Live terminal
Letter N
-
Neutral terminal
or E
-
Earth terminal
This oven must be earthed
The cable used to connect the oven to
the electrical supply must comply to the
specifications given below.
