background image

TX2181

Dual 18”

Direct-Radiating

Subwoofer

General Description:

Technical Specifications:

Key Features:

Dual EVS-18S 18” (457mm) LF Transducers

103 dB Sensitivity, 138 dB Maximum SPL

1000W Continuous (4000W Peak) Power

Handling
Four Integrated Handles for Easy Portability

Mounting Points to Attach Optional TX-W1

Wheel Kit

The Electro-Voice® TX2181 is a dual subwoofer system that is de-
signed to add high-output, high-impact bass response to the TX2152
loudspeaker system.

The TX2181 can move tremendous amounts of air, thanks to dual
EVS-18S high excursion woofers, a well braced enclosure, and a
low distortion port design. The EVS-18S woofers feature a 4-layer
voice coils and cast frames for high power handling and maximum
durability. The TX2181 is designed to be used with a processor and
a dedicated amplifier channel in a biamp configuration.

The TX2181 has many features that make it a versatile subwoofer
system. The enclosure is constructed out of a combination of MDF
and plywood, and coated with EVCoat

TM

for maximum strength and

durability. The unique grille design is very strong, dent resistant, and
features a rotatable logo. Four way handles allow for gripping the
TX2181 in a variety of positions. The recessed input panel with dual
NL4 connectors keeps the connectors hidden and allows for closer
placement to a wall or other boundary. The TX2181 is the same
width and height as the TX2152, providing a single column appear-
ance when stacked, and uses the minimum amount of space when
stored or transported. Mounting points on the rear of the enclosure
allow the optional TX-W1 wheel kit to be attached for easy portability.

Freq. Response

1

(-3 dB): 50 Hz - 160 Hz

Freq. Range

1

(-10 dB): 40 Hz - 1.5 kHz

Rec. Low Pass Frequency: 80 Hz - 120 Hz

Axial Sensitivity

1

: 103 dB (1W/1m)

Max. Calculated SPL

1

: 138 dB

Horizontal Coverage: Omnidirectional

Vertical Coverage: Omnidirectional

Power Handling: 1000W Continuous, 4000W Peak

LF Transducers: (2) EVS-18S, 18 in (457mm) Drivers

Nominal Impedance: 4 Ohms

Minimum Impedance: 2.9 Ohms

Connectors: (2) Neutrik Speakon NL4’s

Enclosure Material: Plywood and MDF with EVCoat

TM

Grille: 16 GA Steel, Black Powdercoat, with

Rotatable Logo

Dimensions (H x W x D): 45.4” x 20.0” x 27.2”

(1154mm x 508mm x 691mm)

Net Weight: 123.5 lbs (56.1 kg)

Shipping Weight: 139.0 lbs (63.1 kg)

1

Half Space Measurement.
