Page 20

The installations described below should be done by qualified service personnel or system installers.

2.1 PACKING LIST

2. INSTALLATION

Please check accessories in the packing before the installation.

Camera

(VIDEO & AUDIO)

Monitor

(and Speaker)

Internet

Alarm

(In & Out)

IR Remote Controller

(Extension Line Connector)

USB Device

(Storage)

RS 232

Please refer to the following diagram for the system connections.

Note: Monitor and Camera must be purchased separately.

2.2 SYSTEM FLOORPLAN

Call
Monitor

Antenna

(Mobile Model only)

Keyboard

Note: 810H/810M without relay

410H/410M with relay
