5
GB
The manufacturer is not liable for damages
caused by an improper use or incorrect
operation of this device.
General description
See the front fold-out page for
illustrations.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Device
- Handgrip
- Protective hood
- Chuck key
- Cutting disc
- Instruction Manual
Description of function
The angle grinder is made for cutting,
scrubbing or brushing metal. There is a
special disc for each of the separate ap-
plications. Please refer to the information
from the disc manufacturer.
Please refer to the descriptions below for
information about the operating devices.
Overview
1 Handgrip
2 Threads for handgrip
3 Speed regulator
4 Switch block
5 On/off switch
6 Threads for handgrip
7 Spindle stop button
8 Power plug
9 Chuck key
10 Cutting disc
11 Protective hood
12 Mounting flange
13 Clamping nut
14 Mounting spindle
15 Adjustment nut
16 Tightening lever
Technical data
Angle Grinder PWS 125 B2:
Rated input voltage
............................... 230-240 V~, 50 Hz
Power input ............................ 1200 W
Idling speed (n) ............3000-12000 min -1
Safety class ..................................... II
Protection category......................... IP 20
Sound pressure level
(L
pA
) ...............92,1 dB(A); K
pA
= 3 dB(A)
Sound power level (L
wA
)
measured .....103,1 dB(A); K
wA
= 3 dB(A)
guaranteed .....106 dB(A); K
wA
= 3 dB(A)
Vibration (a
h
)
Main handgrip 11,237 m/s 2 K= 1,5 m/s 2
Supplemental handgrip
......................... 8,146 m/s 2 K= 1,5 m/s 2
Cutting disc:
Idling speed n
0
................................... max.12200 min -1
Disc speed ....................... max. 80 m/s*
Outer diameter ................... Ø 125 mm
Bore hole ........................ Ø 22,23 mm
Thickness ...................................3 mm
* The grinding disc must keep a rotational
speed of 80 m/s.
Levels of noise and vibration were determi-
ned according to the norms and regulations
in the declaration of conformity.
Technical and visual changes may be made
as part of ongoing development without
announcement. All dimensions, instructions
and specifications are therefore without
guarantee. Legal claims on the basis of the
