12 Micro Motion ® Series 3000 Transmitters and Discrete Controllers
Dimensions
Rack-mount Model 3300/3500
Dimensions in
inches
(mm)
25 HP (25 TE)
5.0 (127) 4× M2.5 × 11
5 1/16
(128.5)
28 HP (28 TE)
5 9/16 (142.2)
19 ″ (486.2 mm) subrack conforms to
DIN 41494 Part 5, and IEC 297-3
Not included as part of Model 3300/3500
3 U
(3 HE)
4 13/16
(122.5)
1
(25.4)
6 11/16
(169.9)
7 11/32
(186.7)
7 29/32
(200.6)
8 33/64
(216.2)
Screw terminal connector (optional)
Rear rail for mounting connectors that
conform to DIN 41612 and IEC 603-2
Not included as part of Model 3300/3500
Approvals tag
Intrinsic safety shield
(Model 3500 only)
1 U = 1 HE = 1.750 inches (44.45 mm)
1 HP = 1 TE = 0.200 inches (5.08 mm)
