4
Introduction
Chapter 1
Embedded and Industrial Computing
Chapter 1:
Introduction
Thank you for choosing the VES-8X2. The VES-8X2 is
Lanner’s flagship Micro ATX COM Express Type 2 carrier
board. It is a standard Micro ATX size carrier board which
allows embedded application developers to deploy
their applications quickly on the COM Express modular
platform.
This carrier board has the following highlighted features:
Expansion Interfaces from Module
-LVDS, IrDA, TV-out
-USB 2.0 (7x), IDE
-PCI Express (1 x PCI, 2x PCIex1, 1 x PCIex16, Express Card)
-COM (1x RS-232/422/485, 1x RS232), and GPIO (4 in, 4
out)
-CF type I/II (1x), SATA (4x), and floppy disk drivers
-LPT (1x)
-Line-in, Mic-in, Line-out, CD Audio-in (provided by
Realtek ALC883)
Outline Dimension
243.84 mm x 243.84 mm
Operating Temperature
0 ~ 60°C (32 ~ 140°F)
Storage Temperature
-20 ~ 80°C (-4 ~ 176°F)
Relative Humidity
0% ~ 90% Relative Humidity, Non-condensing
System Specification
Ordering Information
VES-8x2 COM Express® R2.0 Type 2 Module with Intel® Atom TM D2550
CPU and NM10 Chipset
System
Form Factor Micro-ATX
BIOS
Carrier Board BIOS Socket (Enable/Disable by 2-pin
Jumper)
I/O Chip Winbond W83627HG-AW
Expansion
1 x PCI, 2 x PCIex1, 1 x PCIex16, Express Card
I/O
MIO
1 x EIDE, 4 x SATA, 1 x LPT, 1 x FDD, 1 x RS-232,
1 x RS-232/ 422/ 485, 1 x KB, 1 x Mouse
USB Connector 7 x USB 2.0
DIO 8-bit GPIO
External I/O Connector
PS/2 Mouse (Mini-DIN) & PS/2 KB (Mini-DIN)
LPT (DB-25) over COM2 (DB-9) & VGA (DB-15)
Dual Deck USB ports
RJ45 over Dual USB
6-Ports Audio Jack
Internal I/O Connector
LVDS Connector (HIROSE DF13-40DP-1.25V)
USB: One 5x1, 5x2, pitch 2.54mm Header
IDE: One 20 x 2, pitch 2.54mm Header
IrDA: One 5 x 1, pitch 2.54mm Header
TV-out: One 3 x 2, pitch 2.54mm Header (Supports
CBVS, S-Video, Y/PB/PR)
COM: One 5 x 2, pitch 2.54mm Header (RS-232
/422/485 & Pin-9 5/12V Set by Jumper)
CPU Fan; One 3 x 1, pitch 2.54mm Header
System Fan: Two 3 x 1, pitch 2.54mm Header
Carrier Board Power: One Switch Button
Carrier Board Switch: One Switch Button
GPIO: One 5 x 2, pitch 2.54mm Header
Power Connector: One ATX, One Aux Power (2x2-pin
12V) Connector
Miscellaneous Setting Connector: One 13 x 2, pitch
2.54mm Header (Including Power/Reset Switch,
Power/HDD/Suspend LED, K/B Locked, Speaker Out,
Case Open Detection, Thermal Detection, LCD Bright-
ness Setting & CF Master/Salve Setting)
Audio
Audio Codec Realtek ALC883 Supports 7.1-CH Audio
Audio Interface Line-in, Mic-in, Line-out, CD Audio-in
Connectors
LVDS Connector One HIROSE DF13-40DP-1.25V
Power Connector
One ATX 2 (12 x 2-pin),
One Aux 1 (2 x 2-pin 12V) Power Connectors
Mechanical & Environmental
Power Type AT / ATX
Operating Temperature 0 ~ 60°C (32 ~ 140°F)
Storage Temperature -20 ~ 80°C (-4 ~ 176°F)
Operating Humidity 0% ~ 90% Relative Humidity, Non-condensing
Size (L x W) 243.84 mm x 243.84 mm
Weight 0.5 Kg (1.10 lbs)
Supported COM Express CPU Modules
VES-8X2
COM Express® R2.0 Type 2 Module with Intel®
AtomTM D2550 CPU and NM10 Chipset
