Lanner FW-6486 - Manual (Page 5)

2
Introduction
Chapter 1
Network Application Platforms
Package Contents
Your package contains the following items:
FW-6486 Network Security Platform •
Power cable •
1 crossover Ethernet cable (1.8 meters) •
1 straight-through Ethernet cable (1.8 meters) •
1 RJ45 to DB-9 console cable •
Serial-ATA hard drive cable •
1 threaded screw set •
1 pair of ear bracket for mounting •
Installation environment precaution:
Elevated Operating Ambient - If installed in a 1.
closed or multi-unit rack assembly, the operating
ambient temperature of the rack environment
may be greater than room ambient. Therefore,
consideration should be given to installing
the equipment in an environment compatible
with the maximum ambient temperature (Tma)
specified by the manufacturer.
Reduced Air Flow - Installation of the equipment 2.
in a rack should be such that the amount of air
flow required for safe operation of the equipment
is not compromised. Mechanical Loading -
Mounting of the equipment in the rack should
be such that a hazardous condition is not created
due to uneven mechanical loading.
Mechanical Loading - Mounting of the equipment 3.
in the rack should be such that a hazardous
condition is not achieved due to uneven
mechanical loading.
Circuit Overloading - Consideration should be 4.
given to the connection of the equipment to the
supply circuit and the effect that overloading
of the circuits might have on over-current
protection and supply wiring. Appropriate
consideration of equipment nameplate ratings
should be used when addressing this concern.
Reliable Earthing - Reliable earthing of rack- 5.
mounted equipment should be maintained.
Particular attention should be given to supply
connections other than direct connections to the
branch circuit (e.g. use of power strips).
Physical
Dimensions
Dimensions
(WxHxD) 431 x 44 x 317 mm
Weight 4 kg
Power
Type / Watts 1U ATX SPS / 100W
Input AC 100~240V @50~60 Hz
Approvals and Compliance
CE emission, FCC Class A,
RoHS
