Front Panel Reset Switch (SW_RST_BTN1): This switch
can be a hardware or software reset depending
on the BIOS setting. It works the same as the Reset
Button Connector (JRST_BTN1).
Internal VGA Pin Header (VGAB1)
124 Pin Mini PCI Socket (PCIB1)
Pin No.
Description
Pin No.
Description
1
tIP
2
RING
3
8PMJ-3
4
8PMJ-1
5
8PMJ-6
6
8PMJ-2
7
8PMJ-7
8
8PMJ-4
9
8PMJ-8
10
8PMJ-5
11
LED1_GRNP
12
LED2_YELP
13
LED1_GRNN
14
LED2_YELP
15
CHSGND
16
RESERVED
17
INt-B
18
+5V
19
+3.3V
20
INt-A
21
RESERVED
22
RESERVED
23
GROUND
24
3.3VAUX
25
CLK
26
RSt
27
GROUND
28
+3.3V
29
REO
30
GNt
31
+3.3V
32
GROUND
33
AD31
34
PME
35
AD29
36
RESERVED
37
GROUND
38
AD30
39
AD27
40
+3.3V
41
AD25
42
AD28
Pin No.
Description
Pin No.
Description
43
RESERVED
44
AD26
45
C_BE-3
46
AD24
47
AD23
48
IDSEL
49
GROUND
50
GROUND
51
AD21
52
AD22
53
AD19
54
AD20
55
GROUND
56
PAR
57
AD17
58
AD18
59
C_BE-2
60
AD16
61
IRDY
62
GROUND
63
+3.3V
64
FRAME
65
CLKRUN
66
tRDY
67
SERR
68
StOP
69
GROUND
70
+3.3V
71
PERR
72
DEVSEL
73
C_BE-1
74
GROUND
75
AD14
76
AD15
77
GROUND
78
AD13
79
AD12
80
AD11
81
AD10
82
GROUND
83
GROUND
84
AD9
85
AD8
86
C_BE-0
87
AD7
88
+3.3V
89
+3.3V
90
AD6
91
AD5
92
AD4
93
RESERVED
94
AD2
95
AD3
96
AD0
97
+5V
98
RESERVED-wIP
99
AD1
100
RESERVED-wIP
101
GROUND
102
GROUND
103
AC_SYNC
104
M66EN
105
AC_SDAtA_IN
106
A C _ S D A t A _
OUt
107
AC_BIt_CLK
108
AC_CODEC_ID0
109
AC_CODEC_ID1
110
AC_RESEt
111
MOD_AUDIO_
MON
112
RESERVED
113
AUDIO_GND
114
GROUND
115
S Y S _ A U D I O _
OUt
116
SYS_AUDIO_IN
117
S Y S _ A U D I O _
OUt GND
118
SYS_AUDIO_IN
GND
119
AUDIO_GND
120
AUDIO_GND
121
RESERVED
122
MPCIACt
123
VCC5VA
124
3.3AUX
SATA Connector (SATA1)
Pin No.
Function
1
RSt_BtN
2
GND
3
4
1
2
PIN NO.
Function
PIN NO.
Function
1
R
2
Ground
3
G
4
Ground
5
B
6
Ground
7
H-SYNC
8
Ground
9
V-SYNC
10
Ground
11
Detect-display
Data
12
Deteck-display
CLOCK
2
4
6
8
10
12
1
3
5
7
9
11
124......................2
123......................1
Pin No.
Function
1
GND
2
tX_P
3
tX_M
4
GND
5
RX_M
6
RX_P
7
GND
1
2
3
4
5
6
7
