Illustration and Parts List
3170 Wasson Road • Cincinnati, OH 45209 USA
Phone 513-533-5600 • Fax 513-871-0105
[email protected] • www.jordanvalve.com
Bulletin IM-MK89/89MX-0210
Item
Description
Qty. Item
Description
Qty.
1
Cap
2
21
Name Plate
1
2
Cap Bolts
12
22
Actuator Stem
1
*3
Plate
2
23
Locknut (Adjusting
Wheel)
1
3A
Index Pins (not shown)
4
24
Adjusting Wheel
1
*4
Disc
2
25
Spring Washer
1
*5
Disc Guide
2
26
Adjusting Post
1
*6
Disc Pin
1
27
Spring
1
7
Disc Pin Nut
1
28
Nut
1
9
Spring (Packing)
1
29
Lockwasher
1
*10
Packing
1
30
Actuator Screw
4
11
Packing Follower
1
31
Adapter Plate
1
12
Packing Flange
1
32
Adapter Plate Screw
4
*13
Packing Retainer
1
33
Actuator
1
14
Packing Stud
2
34
Stroke Stop
1
15
Nut
2
46
Chain
1
16
Stem
1
47
Adjusting Tool
1
17
Stem Connector
2
48
Cotter Pin
1
18
Stem Connector Bolt
1
49
Body
1
19
Stem Connector Nut
1
50
Yoke Screw
4
20
Yoke
1
*
Recommended Spare Parts
50
46
21
50
48
47
CLOSED
OPEN
OUTLET
MK89MX
CLOSED
OPEN
INLET
MK89
40
22
23
25
26
27
32
31
34
10
12
16
18
17
24
20
30
29
28
33
49
5
3
4
1
13
11
15
14
19
9
2
7
6
